Crystallizing Agent Work into Workflows

Sources#

• Beyond RAG: Building Agentic Document Workflows with LlamaIndex
• Progressive Crystallization: Turning Agent Exploration into Deterministic, Lower-Cost Workflows in Production

Summary#

An agent platform is a permanent cost centre by default: every execution re-invokes full inference, so the tenth occurrence of a recurring incident costs exactly what the first did, takes a possibly different path, and may reach a worse answer. The waste is that a successful investigation is discarded.

Arun Malik (Microsoft Azure Networking, arXiv 2607.07052, 2026-07-08, case-study) names the fix and reports it running in production on a cloud-network operations platform handling tens of thousands of incidents a month: progressive crystallization — agent exploration is a discovery mechanism, and behaviour it discovers and repeatedly validates gets converted into deterministic workflows that need zero tokens, while the agent layer stays available for what is genuinely novel.

The three-type spectrum#

The taxonomy is the reusable part, and its point is that the three types are lifecycle stages of one discovered behaviour, not three separate systems:

Type	Execution	Determinism	Tokens/run
Type 3 — agent-orchestrated	Sub-agents reason freely within a bounded scope; autonomous reads, deterministic checkpoints, human-in-the-loop gates on writes	~50%	10k–50k
Type 2 — hybrid	Fixed step structure; the LLM is called only at specific stages, for interpretation, classification or summarization. Every action is typed and schema-validated	~90%	1k–5k
Type 1 — deterministic	Pre-coded logic, conditionals, typed API calls; no LLM at runtime	100%	zero

The Type 2 formulation is the sharpest line in the paper: the LLM decides understanding, not what to do. That is the same split Deterministic Pre-Execution Gates draws between the model's judgment and the mechanically-checkable envelope around it, arrived at from the cost side rather than the safety side.

Promotion is gated on evidence, and demotion is automatic#

Transition	Requirements (defaults, configurable)
Type 3 → 2	≥10 successful runs · zero safety violations · ≥90% of runs produce the same action sequence · all auto-generated acceptance tests pass · no human override in the recent window
Type 2 → 1	≥50 successful hybrid runs · LLM classification consistency ≥99% · the deterministic rule covers all observed input variation · full regression suite passes without the LLM · human review of the deterministic logic

Capture is a process-mining step, not a macro recorder: the trace is parsed into an ordered list of tool calls, branch conditions the agent actually acted on are detected, per-step input/output schemas are inferred, a DAG of tool dependencies is built, instance-specific values (device IDs, timestamps) are parameterized, and human-approval points are marked as explicit gates. Acceptance tests are generated from the successful traces, and the candidate playbook must pass them before promotion.

The circuit breaker is what makes this safe to run unattended. Each promoted playbook is monitored and demoted on execution failure, safety violation, or acceptance-test regression. The production anecdote is the whole design in one paragraph: a firmware update changed a command's output format, the deterministic parser broke, the system demoted the playbook to hybrid so the LLM could absorb the new format, and after a run of clean executions it was re-promoted — with no human deciding when to switch.

The claim worth arguing with: autonomy is earned by track record, not by model capability#

"Autonomy is attached to the specific playbook class and action type, based on its evidence, rather than to the capability of the underlying model. A more capable model does not automatically earn more autonomy; a track record does."

This is a direct counter-position to the shape of Harness Shrinkage as Models Improve. The shrinkage thesis says scaffolding is a tax on current model weakness and should be deleted at each release. Crystallization says the opposite about permissions: what a system is allowed to do unsupervised is a property of the demonstrated reliability of a specific behaviour, and a model upgrade does not transfer that evidence. Both can hold — the shrinkage argument is about how much instruction the model needs, this one about how much authority a workflow has earned — but the two point in opposite directions on the same question a team actually faces at every model release, and nothing in the corpus reconciles them.

It also inverts the usual reading of a capability upgrade. On this design a better model does not make the platform cheaper directly; it makes discovery better, and the savings arrive later, when what it discovered crystallizes.

Safety improves with cost, rather than trading against it#

The paper's counter-intuitive claim is that cheaper is safer, and the argument is structural rather than empirical: auditability is unchanged (all three types record full traces); reproducibility rises monotonically ~50% → ~90% → 100%; blast-radius control moves from runtime HITL gates → schema validation → statically verifiable deterministic logic, which is stronger because it can be checked before execution rather than caught during it; compliance moves from conditional-on-a-human-being-present to built-in. A deterministic playbook distilled from an agent run is easier to verify, reproduce and audit than the run it came from.

The production numbers, and what they are not#

Over eight months on the Azure cloud-network platform: Type 1 executions 0% → ~45% (with ~30% hybrid, ~25% agent-orchestrated), per-incident agent cost down >70% while incident volume roughly doubled, >90% of common incident categories resolved autonomously, MTTR from hours to minutes, false-positive remediation under 5% with no customer-visible impact.

The author's own limits, which bound every number above:

• Single organization, single operational domain. Thresholds and ratios should be re-derived elsewhere; only the lifecycle is claimed to be domain-agnostic.
• Platform-level observations, not a controlled comparison. There is no counterfactual arm — nothing establishes what the cost curve would have done without crystallization, and eight months is one maturity trajectory.
• It assumes recurring patterns. In an environment dominated by genuinely novel one-off work, most executions stay Type 3 and the mechanism buys little. This is the scope condition that decides whether the idea transfers to coding agents at all: incident response is unusually repetitive, and a codebase feature request may not be.
• Promotion quality is bounded by trace quality. Auto-generated acceptance tests come from traces; an under-observed pattern can be promoted prematurely, which is exactly why demotion and human review of the final deterministic logic are in the design.

Type 1:2:3 as a maturity metric is the paper's most portable suggestion — the execution mix is a single number that says how much of your agent spend is buying discovery versus re-paying for solved problems.

What the crystallized thing looks like: typed events as the architecture#

Malik's lifecycle says when agent behaviour should become a workflow and says almost nothing about the workflow's shape. Doulcet's LlamaIndex workshop (AI Engineer Singapore 2026, practitioner-opinion, vendor COI — this is a description of LlamaIndex Workflows, not a comparative claim) is the corpus's one detailed account of the shape, and it converges on this page from the other end.

The starting complaint is Type-3-to-Type-2 drift stated as a code smell. A linear pipeline — parse, embed, retrieve, synthesize — works until the day you need to branch: "if the document is a contract, run clause extraction; if it's a report, run summary. Now your pipeline is an if-statement. Two more ifs and it's a mess." The proposed replacement is an event-driven graph: steps are async functions with typed Pydantic events in and out, and the graph is implied by the type signatures — no explicit orchestration object, no wiring code. Four primitives cover it: steps, events, a shared mutable Context, and the Workflow container.

Four properties follow, and each is a claim about what a crystallized workflow buys that a re-invoked agent does not:

• Typed events are the architecture, not an implementation detail. The naming rule is the whole argument: name an event by what it represents (ParsedDocument), never by who produced it (Step2Output), so future-you reads the type signatures and sees the graph. This is the same instinct as Malik's demand that a promoted playbook be legible enough to audit — a Type 1 workflow nobody can read cannot be demoted on evidence.
• Parallelism is declarative. send_event fans out (a step emitting N events of one type runs N branches concurrently), collect_events joins on a count held in the context. No threading, no async-pool management. The same primitive serves per-page document ingestion and deep-research sub-question fan-out — see Deep Research Agents for the tree-shaped case.
• Human review is an event, not an exception. The naive shape (pause the process, send an email, hope the human returns) is "fragile, stateless, untraceable." The prescribed shape emits HumanReviewRequested, persists the whole context durably for minutes or days, and resumes on HumanReviewCompleted — so a hours-long human decision is an ordinary edge in the graph. The consequence is the interesting one: if human review is a typed event you can eval it — measure when humans agreed, when they disagreed, capture what they changed, and feed it into the next eval set. "Treat the human as part of the system you measure, rather than a fail-safe sitting outside it." That is Configurable Human Participation's configurable-agency axis reached from engineering rather than benchmarking, and it is what makes a promotion criterion measurable at Type 2.
• Observability falls out. stream_events emits the same typed events that were written down as architecture, so the trace schema and the design are the same artifact — no separate logging layer. Durability is the paired property: retry the failed step, not the pipeline, and resume from checkpoint after a crash, because "parsing a 500-page contract is not cheap; you don't want to redo it because synthesis had a transient network error."

The boundary condition agrees with this page and is stated as a warning. "If your task is 'answer a single Q&A query over a single document', a function will do." Workflows earn their cost only under branching, parallelism, durability needs, or human-in-the-loop — Malik's admission criteria for leaving Type 3, restated as a caution against reaching for the machinery by default. Neither source measures the alternative.

Four reference shapes are given, and the last is the one with no analogue on this page: contract review (classify → per-clause parallel extraction → risk score → HITL on flagged clauses only → report); deep research; due diligence over a 5,000-document data room (per-type extraction schemas → accumulate a fact store → cross-document reconciliation → surface anomalies); and a living knowledge base — watch sources, reparse on change, re-extract, incrementally reindex, publish fact-level diffs to subscribers, with no StopEvent. A crystallized workflow that never terminates is a category Malik's spectrum does not contain: its Type 1 endpoint is a deterministic procedure with a finish line, and this is a standing process whose output is a change feed.

Connections#

• Document Parsing as the Retrieval Bottleneck — the workflow-shape half of the same subject, treated above: typed events as the contract, declarative fan-out/fan-in, durable HITL, observability as a by-product, and the never-terminating "living knowledge base" shape. It also supplies the upstream dependency this page assumes away — a workflow whose first step parses a document inherits every structure-loss failure that step can make, and no amount of promotion discipline downstream recovers it
• Configurable Human Participation — the same move from two directions: HAS-Bench makes human participation a benchmark variable, the workflow account makes it a typed event, and both do it for the same reason — a human decision you can address as a first-class object is one you can measure agreement, disagreement, and edits against, which is what turns HITL from a fail-safe into an evidence source for promotion
• Deterministic Pre-Execution Gates — the same model/machine division reached from the safety side rather than the cost side; Type 2's "the LLM decides understanding, not what to do" is that split stated as an execution type, and Type 1's statically-verifiable logic is the strongest form of a pre-execution check
• Dynamic Workflows: An Algebra for Agents — the composition primitive this lifecycle retires: where the algebra is about an agent writing a program that composes agents, crystallization is about the program surviving the agent and eventually running without one
• Cost-per-Task Over Cost-per-Token — the cost frame this operationalizes and then escapes: the per-task cost of a solved problem falls to zero rather than to a cheaper model's price, which is a different lever from routing or cascades (the paper positions itself explicitly as orthogonal to FrugalGPT-style per-call cost reduction)
• Harness Shrinkage as Models Improve — the tension worth holding: shrinkage says scaffolding is a tax on current model weakness that each release should retire, crystallization says a workflow's authority is earned by its own track record and does not transfer across a model upgrade
• Implementation Abundance Inverts Product Work — a partial answer to the curation-cost question from a different domain: the cost of curating exploration is paid down by promoting what the exploration proved, so curation is a one-time investment per recurring pattern rather than a recurring tax — but only where the patterns recur, which is the scope condition an exploratory product context may not meet
• Agentic Work Systematization — the same instinct as skills-and-plugins (externalize what you keep re-deriving), pushed one stage further: not "write it down so the agent re-reads it" but "compile it so no agent runs at all"
• Verification as the New Bottleneck — the auto-generated acceptance tests are what make promotion possible, so verification quality is the binding constraint on how much work can leave the agent layer
• Authority and Audit Survive Abundance — resolves this page's upgrade-moment conflict with Harness Shrinkage as Models Improve: shrinkage governs instruction scaffolding, this page's evidence-gated authority is governed by track record alone, and the demotion circuit-breaker is what makes the upgrade moment decision-free on the authority side

Open Questions#

• Does the lifecycle transfer out of IT operations? Every number here comes from incident response, which is unusually repetitive and has a crisp success oracle (the incident resolved). Coding, product and research work have neither property in the same degree. The falsifiable version: apply the Type 3→2→1 promotion criteria to an agentic coding pipeline and measure whether the deterministic share rises at all over comparable time.
• The platform-level cost curve has no counterfactual arm. How much of the >70% per-incident cost fall is crystallization, and how much is ordinary model-price decline plus caching over the same eight months? A controlled comparison, or a decomposition against contemporaneous list prices, would separate them.

Resolved Questions#

• Crystallization and harness shrinkage give opposite instructions at a model upgrade — delete the scaffolding versus keep the evidence-gated permissions. Which governs, and does the answer differ for instruction scaffolding versus authority scaffolding? Answered: Authority and Audit Survive Abundance — neither governs the other; they govern disjoint objects, separable by one test: can the model being better make this line unnecessary? Instruction scaffolding encodes a task prior (shrinkage governs — ablate at every release); this page's authority scaffolding encodes a boundary plus a local evidence record, neither of which a capability jump supplies — and the security corpus makes the stronger claim that authority cannot migrate inward, because a component that grants its own scope is circular ("you can delegate judgment; you cannot delegate authorization"). The sort is by what a line encodes, not where it lives (a prompt-borne scope declaration is still authority-class; the derived page grounds this in the constraint/request asymmetry). At upgrade day the reconciliation is already in this page's design: the launch pass prunes instructions, permission grants stay untouched, and the demotion circuit-breaker re-earns authority from evidence continuously — so the upgrade moment requires no authority decision at all.

Sources#

• Beyond RAG: Building Agentic Document Workflows with LlamaIndex — Pierre-Loic Doulcet, AI Engineer Singapore 2026 (practitioner-opinion, LlamaIndex vendor COI; a description of one framework, with no comparison and no measurement): Part V — the four primitives, typed-event naming rule, send_event/collect_events, durable HITL, stream_events observability, the when-NOT-to-use-a-workflow boundary, and the four reference shapes. The event-graph and durable-pause diagrams exist only as slide images and were read via the image two-pass; full source treatment and parse warnings on Document Parsing as the Retrieval Bottleneck
• Progressive Crystallization: Turning Agent Exploration into Deterministic, Lower-Cost Workflows in Production — Arun Malik, Microsoft Azure Networking, arXiv 2607.07052, 2026-07-08 (case-study, sole author, first-party account of the author's own production platform, not peer reviewed; no controlled comparison): §III + Table I the execution-type taxonomy, §IV + Table II the promotion criteria and trace-extraction algorithm, §V the economic model, §VI + Table III safety monotonicity, §VII the demotion circuit-breaker and the firmware-update episode, §VIII the eight-month production figures, §IX the author's limitations. docling verify ok — 4pp, 3 tables, 3 pictures, no collapse or shift; the three figures restate numbers stated in prose, so the image two-pass was not load-bearing
